Product features:
Light alloy steel body, tubing, specific quantity.
Frictionless linear ball bushing motion accurate repeatability.
3/4 inch stroke (retraction) for check groove.
Large diameter adjustable range.
6 1/2" to 60" diameter range with 5 models - larger sizes available.
Adjustable measuring depth from 0 to 3 ".
The active mechanism immediately reverses the measurement direction. There is no loose section.
Quick action gear rack fine tuning, quick setting.
Cemented carbide ball contact.
Three cemented carbide dowel gauges.
Several standard contact methods.
Easy to set with gauge block and 600 series adjustable gauge set position or qualified part.
Hardwood storage box is suitable for all types.
Product parameters
2900 SERIES SPECIFICATIONS |
MODEL | ID-OD RANGE | LENGTH | APPROX. WGT |
2910 | 6 1/2"-14" | 23-1/4" | 3 lb. 5 oz. |
2911 | 14"-24" | 33-1/4" | 3 lb. 14 oz. |
2912 | 24"-36" | 45-1/4" | 4 lb. 10 oz. |
2913 | 36"-48" | 57-1/4" | 5 lb. 6 oz. |
2914 | 48"-60" | 69-1/4" | 6 lb. 2 oz. |
Gage supplied with AGD Group 2 .0005" dial indicator with rev counter & 1/2" travel & 2930 measuring tips unless otherwise requested. Available with .0001" indicator with .200 travel.
Metric indicators available. |
|
ip No. | Diameter | Thickness |
2920-1 & 2 | 1.000" | .050" |
2921-1 & 2 | 1.000" | .100" |
2922-1 & 2 | 1.000" | .200" |
2930-1 & 2 | .250" | - |
